45°Integrated slant-bed CNC lathe (with tool arrangement, turret and power head) GP-22P

Product Drawings

ltemS i z eGP-22P
Working range   Max.Turning diameter over bedφ300
   Max.Turning swing dia over carriageGang:φ90
   Max.Turing diameteφ220
   Max.Processing lengthGang:200
Max.X/Z axis trave   Xaxis25C
   (N·m)Recommend the X axis motor torque≥4
Z axis250
(N·m)Recommend the Zaxis motor torque≥4
Feed screwXaxis ball-screw2510-C3
   Z axis ball-screw2510-C3
Bed   Bed slant angle45° integral casting bed
   Linear guide's span290
Spindle   (tpm)  Max.spindle speed4500
   Spindle through-hole diameterφ28
   Spindle nose size
   (kW)Recommend the spindle motor power2.2
   Hydraulic chuck or collet chuckφ20collet chuck
