45°Single Spindle Single Turret Single Y-axis Turning Centre Optical(Linear Rail)-Supplier

Product Drawings

ltem

Size

GP-400Y

Working range

Max.Turning diameter over bed

φ580

Max.Turning swing dia over carriage

φ330

Max.Turing diameter

φ250(When the X, Y axis and power tool turret are protected as a whole)

Max.length between chuck and tailstock cente

500

Max.Processing length

450

Max,X/Z axis rave

Xaxis

230

Yaxis

120

Z axis

530

R axis(Tailstock travel)

530

Feed screw

Controlaxis

5Axis(X2+Y2+Z2+R+C1)

Xaxis ball-screw

3208-C3

(N·m)Recommend the X axis motor torque

>10

Y axis ball-screw

3208-C3

(N·m)Recommend the Y axis motor torque

>10

Zaxis ball-screw

3208-C3

(N·m)Recommend the Zaxis motor torque

>15

R axis ball-screw

3208-C3

(N·m)Recommend the R axis motor torque

>10

Bed slant angle

45° integral casting bed

Linear guide's span

400

Spindle

(rpm)Max.spindle speed

4500

Spindle through-hole diameter

φ61

Spindle nose size

A2-6

(KW)Recommend the spindle motor power

7.5

Hydraulic Tailstock

Diameter of Tallstock center sleeve

φ80

Max.stroke of Tailstock center sleeve

120

Taper of Tailstock center sleeve

MT4
